All-Flo F100 Pump 1″ ALL-PUR FDA Passivated Stainless Steel AODD – F-Series

F100

Pump Size
1”

Air inlet
1/4” FNPT

Liquid Inlet
1 1/2”

Liquid discharge
1 1/2″

Connection type
TRI-CLAMP

Max flow rate
182 LPM

Max pressure
8.2 BAR (120 PSI)

Max diameter solids
6.4MM

Max suction lift capacity
5.2M DRY, 9.1M WET

Pump Details

All-Flo’s All-Pur FDA (F-Series) and food grade (G-Series) Air operated double diaphragm (AODD) pumps are ideal for a range of food and beverage fluid transfer applications, including beer, wine, cider and spirits. The F-Series offers an easy to maintain design with passivated stainless steel wet end parts. The G-Series features a unique design for gentle handling of products, an integrated muffler and a compact form. Both the F-Series and G-Series Air operated double diaphragm (AODD) pumps are FDA, ATEX and CE Compliant.

CONSTRUCTION
Wet End: Passivated Stainless Steel
Air End: Aluminum
Diaphragm: Hytrel®, PTFE, Santoprene®
Valve: Buna-N, PTFE, Santoprene®
Seat: Stainless Steel
O-Rings: Buna-N, EPDM, PTFE
Hardware: Stainless Steel
Muffler: Metal, Plastic
