Wilden PS1510 Pump 76 mm (3”) Pro-Flo® SHIFT Brahma™ Bolted Metal AODD
PS1510
Pump Size
3”
Air inlet
3/4” FNPT
Liquid Inlet
3”
Liquid discharge
3”
Connection type
DIN/ANSI (Flanged)
Max suction lift capacity
7.1 m (23.3′) Dry, 9.0 m (29.5′) Wet
Max flow rate
882 lpm (233 gpm)
Max pressure
8.6 bar pressure (125 psi)
Max diameter solids
76mm
Displacement per stroke
4.7 L (1.24 gal)
Pump Details
The Renowned Wilden Brahama Series air operated double diaphragm (AODD) pumps excel in securely and efficinetly transferring solid-laden slurries. Distinguished by its distinctive top inlet and bottom discharge configuration, the Wilden Brahama Series incorporates flap valves, facilitating the smooth passage of sizeable solids. This design effectively mitigates the risks of product entrapment and sediment settling, particularly beneficial for intermittent duty applications.
The Wilden Brahama offers generous clearance and flow through design, these pumps boast an impressive capacity for accommodating large solid while safeguarding against clogging. The bolted construction ensures exceptional containment, enabling the pump to handle compressible solids up to 76mm (3″) in size.
- Flap valve design for large-solids passage
- Top inlet, bottom discharge for easy transfer of sediment and solid-laden fluids
- Powered by Pro-Flo® SHIFT or Turbo-Flo™ air distribution systems (ADS)
