Wilden PS15 Pump 76 mm (3″) Pro-Flo®SHIFT Saniflo™ FDA Series Clamped Metal AODD

PS15

Pump Size
3”

Air inlet
3/4” FNPT

Liquid Inlet
3”

Liquid discharge
3”

Connection type
Tri-Clamp

Max suction lift capacity
Rubber – 6.6 m (21.6’) Dry, 8.6 m (28.4’) Wet
EZ-Install TPE – 6.3 m (20.7′) Dry, 8.6 m (28.4′) Wet
Full-Stroke PTFE – 6.2 m (20.2′) Dry, 8.6 m (28.4′) Wet

Max flow rate
Rubber – 927 lpm (245 gpm)
EZ-Install TPE – 901 lpm (238 gpm)
Full-Stroke PTFE – 916 lpm (242 gpm)

Max pressure
8.6 bar pressure (125 psi)

Max diameter solids
9.5mm

Displacement per stroke
Rubber – 5.2 L (1.38 gal)
EZ-Install TPE – 5.3 L (1.41 gal)
Full-Stroke PTFE – 5.1 L (1.34 gal)

Pump Details

The Wilden Saniflo FDA series pumps cater to standard food processing needs that don’t necessitate the hygienic series (HS) or clean-in-place (CIP) features. Ideal for the sanitary environments handling high acid, high sugar and high fat substances, these pumps offer straightforward installation and a sturdy build. Compliant with FDA, CE,EC 1935/2004 and ATEX standards, they ensure reliability and regulatory adherence

  • Tri-clamp connections with wingnut clamped design
  • Quick breakdown/reassembly for cleaning
  • Greater flow – more gallons pumped per SCFM
  • Two air distribution system options:
    • Pro-Flo® SHIFT: multiple material options, high efficiency, high flow
    • Pro-Flo: durable, economical, one material option
